HP JG221A Installation Guide

1
Product overview
Switch models
Table 1 Switch models in the HP A3100 v2 Switch Series
Sub-series
Model
Product code
Description
Alias
HP A3100 v2 SI
Switch Series
Non
PoE
JG221A
HP A3100-8 v2 SI Switch
A3100-8 v2 SI
JG222A
HP A3100-16 v2 SI Switch
A3100-16 v2 SI
JG223A
HP A3100-24 v2 SI Switch
A3100-24 v2 SI
HP A3100 v2 EI
Switch Series
Non
PoE
JD318B
HP A3100-8 v2 EI Switch
A3100-8 v2 EI
JD319B
HP A3100-16 v2 EI Switch
A3100-16 v2 EI
JD320B
HP A3100-24 v2 EI Switch
A3100-24 v2 EI
PoE
JD311B
HP A3100-8-PoE v2 EI Switch
A3100-8-PoE v2 EI
JD312B
HP A3100-16-PoE v2 EI Switch
A3100-16-PoE v2 EI
JD313B
HP A3100-24-PoE v2 EI Switch
A3100-24-PoE v2 EI
Panel views
A3100-24 v2 SI/A3100-24 v2 EI
Front panel
Figure 1 A3100-24 v2 SI/A3100-24 v2 EI front panel
1
2 3
456
78
(1) Speed LED for a 10/100Base-TX Ethernet port
(2) 10/100Base-TX Ethernet port
(3) Speed LED for a combo interface
(4) Console port
(5) Combo interface (10/100/1000Base-T Ethernet port on the left, 100/1000Base-X SFP port on the right)
(6) Link/Act LED for a combo interface
(7) Link/Act LED for a 10/100Base-TX Ethernet port
(8) Power LED
