HP Laser Jet 3390

13. Removal of fuser
a.) On the right of printer, press the two tabs on the two gears (callout 31) to release and remove gears.
b.) Disconnect four connectors (callout 32) from the ECU. Remove the wire harness for the guises (callout 33).
c.) Pull the tabs on the wire harness holders (callout 34), then slide wire harness holders towards the center on
printer and remove.
d.) Disconnect three wire connectors (callout 35).
34
32
33
31
35
