Printer views
●
Printer front view
●
Printer back view
●
Interface ports
●
Control-panel view (keypad control panel, M607n, M607dn, M608n, M608dn, M609dn models)
●
Control-panel view (touchscreen control panel, M608x, M609x models)
Printer front view
1 M607n, M607dn, M608n, M608dn, M609dn: Keypad control panel
M608x, M609x: Color touchscreen display control panel (tilts up for easier viewing)
2 Output bin
3 Latch to release the cartridge door (access to the toner cartridge)
4 On/o button
5 Cartridge door and Tray 1
6 Tray 2
7 Easy-access USB printing port
8 Hardware integration pocket (for connecting accessories and third-party devices)
9 1x550-sheet paper feeder, Tray 3 (included with the M608z and M609z models; optional for the other models)
