7. Lift up the right side of the fuser assembly to release it from the chassis, and then remove the fuser
assembly.
Figure 5-79 Remove the fuser assembly (6 of 6)
NOTE: When replacing the fuser assembly, be sure to transfer the delivery-sensor PCA from the old
fuser to the new one.
