5. Release one tab (callout 7) and then remove the wire-harness retainer (callout 8).
Figure 5-77 Remove the fuser (4 of 6)
7
8
6. Remove three screws (callout 9).
Figure 5-78 Remove the fuser assembly (5 of 6)
9
98 Chapter 5 Removal and replacement ENWW
