Table 8-17 Internal components (3 of 3)
Ref Description Part number Qty
2 Bushing RC1-1953-000CN 1
5 Link, coupling lower RC1-2485-000CN 1
6 Link, coupling top RC1-2494-000CN 1
8 Guide, tray right RC1-8390-000CN 1
9 Screw, D XA9-1670-000CN 9
Not shown Guide, tray left RC1-8389-000CN 1
22 Screw, with washer, M3x8 XA9-1420-000CN 1
24 Motor, stepping, dc RK2-0777-000CN 1
26 Speaker assembly RM1-3410-000CN 1
ENWW Product base 231
