Alphabetical parts list
Table 8-18 Alphabetical parts list
Description Part number Table and page
Bushing RC1-1953-000CN Internal components (3 of 3)
on page 231
Control-panel assembly, Asian RM1-5179-000CN ADF components on page 215
Control-panel assembly, Western RM1-5178-000CN ADF components on page 215
Control-panel overlay See Control-panel
overlay on page 207.
External assemblies
on page 213
Cover, front RL1-1160-000CN External covers, printer
on page 223
Cover, left scanner RM1-3076-020CN ADF components on page 215
Cover, left RC1-8373-000CN External covers, printer
on page 223
Cover, rear RC1-2474-020CN External covers, printer
on page 223
Cover, right scanner RM1-3077-000CN ADF components on page 215
Cover, right RC2-5800-000CN External covers, printer
on page 223
Cover, top RC2-5792-000CN ADF components on page 215
Cover, top (scanner support-frame) RL1-1161-000CN External covers, printer
on page 223
Delivery tray assembly RM1-3059-000CN External assemblies and print
cartridge on page 221
Door, print cartridge RC1-8372-000CN External covers, printer
on page 223
Engine-controller-PCB assembly RM1-3404-000CN Internal components (2 of 3)
on page 229
Fax card, EMEA CC396-60001 Formatter and fax card
on page 225
Fax card, US/AP CC392-60001 Formatter and fax card
on page 225
Flat, flexible cable (FFC) scanner RK2-1214-000CN ADF components on page 215
Formatter, Asian CC541-60001 Formatter and fax card
on page 225
Formatter, Western CC391-60001 Formatter and fax card
on page 225
Frame assembly RM1-3063-000CN Frame assembly on page 217
Fuser, 110-127V RM1-5363-000CN Internal components (1 of 3)
on page 227
Fuser, 220-240V RM1-5364-000CN Internal components (1 of 3)
on page 227
232 Chapter 8 Parts ENWW
