Parts removal order
Use the following diagrams to determine the order in which parts must be removed.
Figure 6-2 Parts-removal tree, scanner assembly
Scanner side covers
Separation-pad set (not the entire assembly)
Scanner assembly
Link assemblies and scanner support-frame springs
Scanner assembly top cover
Top-cover assembly
Pickup roller
Control-panel bezel
Media lever and torsion spring
Separation-pad assembly
White plate
Control-panel assembly
NOTE: The separation-pad set and the separation-pad assembly are two different assemblies.
The separation-pad set consists of the pad, clear plastic sheet, and the pad cover. The separation-pad
set is a user-replaceable assembly.
The separation-pad assembly consists of the separation lever, tension spring, feed arm, and the
components of the separation-pad set. The separation-pad assembly is not a user-replaceable
assembly.
Only trained service personnel should attempt to replace the separation-pad assembly.
ENWW Service approach 71
