HP LaserJet M1319 - Multifunction Printer - Page 90

Figure 6-3 Parts-removal tree, product base
Print cartridge
Transfer roller
Media input tray
Printer side covers
Rear cover and fuser cover
Power supply
Scanner assembly
Print-cartridge door
Front cover
Scanner support-frame
Engine controller unit
Laser/scanner assembly
Main motor
Fuser assembly
Pickup assembly
Front cover
Speaker assembly
Formatter
Handset
NOTE: In Figure 6-3 Parts-removal tree, product base on page 72, the front cover is listed twice.
72 Chapter 6 Removal and replacement ENWW
