2. Disconnect two connectors (callout 1), and then release the wire harnesses from the guide (callout 2).
Reinstallation tip When the upper cover is reinstalled, make sure that these wire harnesses (near the
connectors) are correctly routed under the cover.
Figure 1-119 Remove the fuser (2 of 8)
1
2
3. Disconnect one connector (callout 1).
Figure 1-120 Remove the fuser (3 of 8)
1
