HP LaserJet Pro Color MFP M476dn

Reinstall the fuser
To reinstall you must insert the tabs (callout 1) on the fuser frame into the slots on the product chassis
(callout 2).
CAUTION: The fuser frame must be flush with the product chassis before you install the two fuser
mounting screws. Do not use the screws to pull the fuser frame against the chassis.
Figure 1-126 Reinstall the fuser
1
2
92 Chapter 1 Removal and replacement ENWW
