2. Slightly push the cover toward the front of the product to engage the front-locking tabs (callout 1) with
the holes in the chassis.
NOTE: Make sure that the right-front edge of the upper cover (where the product right-front cover will
be installed) is correctly positioned on the chassis.
Figure 1-54 Reinstall the upper-cover assembly (2 of 3)
1
3. Carefully pry the right-rear corner of the upper cover away from the product until the cover fits over the
chassis.
Lower the cover onto the product.
Figure 1-55 Reinstall the upper-cover assembly (3 of 3)
44 Chapter 1 Removal and replacement ENWW
