HP LaserJet Pro Color MFP M476dn - Page 73

4. Disconnect one connector (callout 1).
Figure 1-73 Remove the ITB (3 of 6)
1
5. Carefully lift up on the front of the ITB to release it.
CAUTION: Wear gloves when handling the ITB, and avoid touching the black plastic transfer belt. Skin
oils on the belt might cause print-quality problems. Lift the ITB as shown below, by using the hard-
plastic edges of the ITB.
Figure 1-74 Remove the ITB (4 of 6)
ENWW Removal and replacement procedures 55
