4. Disconnect one connector (callout 1), and then remove six screws (callout 2).
Figure 1-103 Remove the high-voltage power-supply PCA (4 of 5)
1
2
5. Release ten tabs (callout 1), and then remove the high-voltage power-supply PCA.
Figure 1-104 Remove the high-voltage power-supply PCA (5 of 5)
1
ENWW Removal and replacement procedures 77
