Step 4: Transfer
The transfer bias is applied to the transfer roller to give the paper a positive charge. The positively charged
paper attracts the negatively charged toner from the photosensitive drum surface.
Figure 1-16 Primary transfer
Transfer roller
Paper
Transfer bias
Photosensitive
drum
ENWW Engine laser/scanner system 23
