HP LaserJet Pro M402d

Figure 1-21 Pickup, feed, and delivery system
Duplex paper path
Simplex paper path
Duplex block
Pickup-and-feed block
Fuser-and-delivery block
Table 1-12 Pickup, feed, and delivery system functions
Function Supported feature
Cassette media size detection No
Cassette media presence detection Yes
Cassette media level detection No
28 Chapter 1 Theory of operation ENWW
