4. Grasp the large handles on the ITB, pull it straight out of the product until it stops, and then pull up to
remove it from the product.
CAUTION: The ITB is a sensitive component. Be careful when handling the ITB so that it is not
damaged. Always place the ITB in a safe and protected location.
Figure 2-20 Remove the intermediate transfer belt (3 of 3)
Reinstallation tip If you are installing a replacement ITB, make sure that you remove all of the packing
tape and the protective cover sheet.
Reset the New Transfer Kit setting at the control panel
NOTE: Use this procedure to reset the internal page count if a replacement ITB and secondary transfer
roller are installed.
1. At the control panel, press the Home button .
2. Open the following menus:
●
Administration
●
Manage Supplies
●
Reset Supplies
●
New Transfer Kit
3. Use the Down arrow button
to highlight the Yes item, and then press OK to select it.
ENWW Removal and replacement procedures 99
