HP M750 series

4. Close the inner cover, and then release two tabs on each stopper (callout 1) with a small flat-blade
screwdriver (callout 2).
Figure 2-44 Remove the front-door assembly (3 of 4)
1
NOTE: Each tab is at the end of the stopper that is closest to the product.
1
2
118 Chapter 2 Removal and replacement ENWW
