HP M750 series

5. Position the door as shown below (callout 1), and then slide the front-door assembly in the direction
that the arrow indicates to remove it from the product.
Figure 2-45 Remove the front-door assembly (4 of 4)
1
ENWW Removal and replacement procedures 119
