4. Release one tab (callout 1), and then remove the guide (callout 2).
TIP: Release the wire harnesses from the guide as you remove it.
Figure 2-48 Remove the right-door assembly (3 of 6)
2
1
5. Disconnect two connectors (callout 1).
Figure 2-49 Remove the right-door assembly (4 of 6)
1
ENWW Removal and replacement procedures 121
