HP M750 series

4. Remove two screws (callout 1), move the registration sensor flag (callout 2) to the up position, and then
pull the paper pickup assembly (callout 3) toward you to remove it.
Figure 2-61 Remove the paper pickup assembly (4 of 4)
1
2
3
130 Chapter 2 Removal and replacement ENWW
