4. Release one tab (callout 1) and slide the formatter fan away form the sheet-metal plate to remove it.
Figure 2-155 Remove the formatter fan (4 of 5)
1
5. Release three tabs (callout 1) and remove the fan (callout 2) from the holder (callout 3).
Figure 2-156 Remove the formatter fan (5 of 5)
2
3
1
196 Chapter 2 Removal and replacement ENWW
