HP M750 series

2. Disconnect three intermediate connectors (callout 1), and then release the cables (callout 3) from the
cable guides (callout 2) on the top and right sides of the DC controller PCA.
Figure 2-158 Remove the DC controller PCA (2 of 3)
2
1
3
3. Remove four screws (callout 1), and then remove the DC controller PCA (callout 2).
Figure 2-159 Remove the DC controller PCA (3 of 3)
1
2
198 Chapter 2 Removal and replacement ENWW
