HP M750 series

2. Disconnect three connectors (callout 1), remove two screws (callout 2), and then unroute the cable
(callout 3) as you remove the driver PCA (callout 4).
Figure 2-170 Remove the driver PCA (2 of 2)
2
3
1
4
208 Chapter 2 Removal and replacement ENWW
