HP M750 series

4. Slide the right door (callout 1) and the arm (callout 2) in the direction that the arrow indicates to remove
them together, and then remove the arm from the right door unit.
Figure 2-180 Remove the 1 x 500 right door (3 of 3)
2
1
ENWW Removal and replacement procedures 217
