Description Spare part number
●
WSVGA display assembly w/ touchscreen 617081–001
Display cable kit includes the following cables: 577933-001
●
WLAN antennas (2) with cables
●
Dual microphone with cable
●
WWAN antennas (2) with cables on select models
Display back cover (includes logo)
●
For use with touch screen, espresso 625724-001
●
For use with touch screen, red 598458-001
●
For use with touch screen, blue 598459-001
●
For use with non-touch screen, espresso 625725-001
●
For use with non-touch screen, red 606201-001
●
For use with non-touch screen, blue 606970-001
Before removing the display assembly:
1. Shut down the device. If you are unsure whether the device is off or in Hibernation, turn the
device on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the device.
3. Disconnect the power from the device by first disconnecting the power cord from the AC outlet
and then disconnecting the AC adapter from the device.
4. Remove the battery (see
Battery on page 38).
5. If your device has WWAN capability, remove the SIM (see
SIM on page 39).
6. Remove the following components:
a. Keyboard (see
Keyboard on page 43)
b. Hard drive (see
Mass storage devices on page 50)
c. WLAN module (see
WLAN module on page 53)
d. Top cover (see
Top cover on page 56)
66 Chapter 4 Removal and replacement procedures
