Device
Interface
IP address
Device
Interface
IP address
Hub 2 Loop0 2.2.2.2/32
Configuration procedure
1. Assign an IP address and subnet mask to each interface, as shown in Table 6. (Details not
shown.)
2. Configure ADVPN:
a. Configure the VAM server:
# Create an ADVPN domain named abc.
<Server>system-view
[Server]vam server advpn-domain abc id 1
# Set the pre-shared key to 123456.
[Server-vam-server-domain-abc]pre-shared-key simple 123456
# Configure the VAM server not to authenticate VAM clients.
[Server-vam-server-domain-abc]authentication-method none
# Enable the VAM server.
[Server-vam-server-domain-abc]server enable
# Create hub group 0.
[Server-vam-server-domain-abc]hub-group 0
# Specify private IPv4 addresses for hubs in hub group 0.
[Server-vam-server-domain-abc-hub-group-0]hub private-address 192.168.0.1
[Server-vam-server-domain-abc-hub-group-0]hub private-address 102.168.0.2
# Specify a private IPv4 address range for spokes in hub group 0.
[Server-vam-server-domain-abc-hub-group-0]spoke private-address range
192.168.0.0 192.168.0.255
[Server-vam-server-domain-abc-hub-group-0]quit
[Server-vam-server-domain-abc]quit
b. Configure Hub 1:
# Create a VAM client named hub1.
<Hub1>system-view
[Hub1]vam client name hub1
# Specify ADVPN domain abc for the VAM client.
[Hub1-vam-client-hub1]advpn-domain abc
# Specify the VAM server.
[Hub1-vam-client-hub1]server primary ip-address 100.1.1.100
# Set the pre-shared key to 123456.
[Hub1-vam-client-hub1]pre-shared-key simple 123456
# Enable the VAM client.
[Hub1-vam-client-hub1]client enable
c. Configure Hub 2:
# Create a VAM client named hub2.
<Hub2>system-view
[Hub2]vam client name hub2
# Specify ADVPN domain abc for the VAM client.
[Hub2-vam-client-hub2]advpn-domain abc
# Specify the VAM server.
