Solid-state drive (SSD)
Description Spare part number
128 GB, SATA-3, SS 914923-001
Before removing the solid-state drive, follow these steps:
1. Turn o the computer.
2. Disconnect the power from the computer by unplugging the power cord from the computer.
3. Disconnect all external devices from the computer.
4. Remove the bottom cover (see Bottom cover on page 25).
5. Disconnect the battery (see Battery on page 30).
Remove the solid-state drive:
1. Remove the Phillips M2.0×3.0 screw (1) that secures the drive to the system board.
2. Remove the drive (2) by pulling it away from the connector.
NOTE: M.2 solid-state drives are designed with notches to prevent incorrect insertion.
Reverse this procedure to install the solid–state drive.
Component replacement procedures 31
