Unplug the AC or DC power from the switch before mounting it.
Rack Mounting: To attach the accessory kit brackets to the switch, use the eight 8-mm M4 screws and
a #1 Phillips (cross-head) screwdriver. Then secure the brackets to the rack by using the four number
12-24 screws.
Table or Desktop Mounting: Attach the four self-
adhesive pads (included in the accessory kit) to the
bottom corners of the switch.
HPE OfficeConnect 1920S Switch Series 5

HP OfficeConnect 1920S 8G Specifications

General

Model	HP OfficeConnect 1920S 8G
Switching Capacity	16 Gbps
Forwarding Rate	11.9 Mpps
Power over Ethernet (PoE)	No
Mounting	Desktop, Rack-mountable
Layer	Layer 2
Power Supply	Internal
Ports	8 x 10/100/1000 RJ-45
Jumbo Frame Support	Yes
Management	Web-based GUI, SNMP
Operating Temperature	32°F to 104°F (0°C to 40°C)
Operating Humidity	15% to 95% non-condensing
