Connect a PC directly to the switch with a standard

Ethernet cable. Before you connect the switch to

the network, configure the IP Address and Subnet

Mask for the PC. The IP addressing allows the

switch to communicate with the switch through the

Web browser on your PC. The switch factory

default settings include the following values:

Parameter Factory Default Setting

User name admin

Password <blank>

IP address 192.168.1.1

Subnet Mask 255.255.255.0

Default gateway not set

To enable the switch to operate in your network,

modify the IP configuration as needed. See

Example: Initial Switch Configuration.

7. Connect the network cables.

NOTE:

For transceiver connections, install and use

only HPE SFP transceivers supported by the

switch. See SFP Installation Notes.

Example: Initial Switch Configuration

Procedure

1. Reconfigure the PC’s IP address and Subnet Mask so that it can communicate with the switch.

a. Click Start > Control Panel. Type adapter in the search box, and then click View network

connections.

b. Select and right-click Local Area Connection, then click Properties.

c. Click the Networking tab. Select Internet Protocol Version 4 (TCP/IPv4) under This connection

uses the following items, and then click Properties.

NOTE:

Be sure to record all your PC’s current IP settings to be able to restore them later.

d. On the General tab, click Use the following IP address.

e. For IP address, enter an IP address in the same range as the switch’s default IP address. For

example, enter 192.168.1.12.

Example: Initial Switch Configuration 7
