HP OMEN 24 User Manual

8
How to order parts
The HP authorized repair center can purchase the power board from HP.
Power board
Description
HP spare part number
Manufacturer part number
PSU OMEN 24 (1
st
source)
N49783-001
PLPCME471GACT
PSU OMEN 24 (2
nd
source)
N49783-002
PLPCME581KACM
Capacitors and connectors are available for purchase from the following EU distributors:
 RS Component: Capacitors | RS Components (rs-online.com)
 Farnell: Farnell UK - Electronic Components Distributor
Capacitors by distributor
Component description
Location
Component
distributor
Distributor part number
NA
NA
NA
NA
Connectors by manufacturer
Component description
Location identifier
Component
distributor
Distributer part number
HDMI
CN502/CN503
RS
SD-47151-001
(Molex)
DP
CN501
Farnell
DP1RD20JQ1
(JAE)
PHONE JACK
CN601
RS
913-1021
(RS PRO)
NOTE: Rear cover and chassis need to be modified to hold connector. Connector may need modifications to
meet functional, safety and regulatory requirements accordingly if it doesn’t match exactly.
You can purchase cables from the HP part store at https://partsurfer.hp.com/Search.aspx.
Internal and External Power Supplies are available for purchase from the following EU distributor: EET
https://www.eetgroup.com/en-eu/
16
KEY
1
17
CONNECTOR BOARD
1
18
REAR_COVER L238W-Ghp3-p3
1
19
DECO_REAR_COVER
1
20
HINGE ASS'Y
1
21
SCREW M4 10
4
22
COVER_VESA L238W-Ghp3-p3
1
23
stand ass'y NA NA
1
24
stand clamp N/A NA
1

HP OMEN 24 Specifications

General

Haze rate	25 %
Color depth	8 bit
Color gamut	90 %
Pixel pitch	0.28 x 0.28 mm
Screen shape	Flat
Pixel density	93 ppi
Display diagonal	23.8 \
Surface hardness	3H
Anti-glare screen	Yes
Native aspect ratio	16:9
Vertical scan range	60 - 165 Hz
Horizontal scan range	30 - 210 kHz
sRGB coverage (typical)	99 %
Contrast ratio (typical)	1000:1
Display number of colors	16.7 million colors
Display diagonal (metric)	60.5 cm
Display brightness (typical)	300 cd/m²
Supported graphics resolutions	640 x 480 (VGA), 720 x 400, 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1280 x 800 (WXGA), 1440 x 900 (WXGA+), 1600 x 900, 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080)
DisplayPort version	1.4
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Energy efficiency scale	A to G
Power consumption (max)	40 W
Power consumption (standby)	0.5 W
Power consumption (typical)	25 W
Package depth	164 mm
Package width	595 mm
Package height	407 mm
Package weight	9330 g
Pivot angle	-90 - 90 °
Tilt angle range	-5 - 23 °
Height adjustment	100 mm
Panel mounting interface	100 x 100 mm
Product color	Black
Country of origin	China
Market positioning	Gaming
HP segment	Home
AMD FreeSync type	FreeSync Premium

Weight and Dimensions

Depth (with stand)	198.3 mm
Width (with stand)	539.4 mm
Height (with stand)	465.3 mm
Weight (with stand)	6350 g
Depth (without stand)	52 mm
Height (without stand)	321.5 mm
