15
1) Unlock 11 screws from the MF as the picture 1.
2) Disassemble DECO from the monitor and disassemble MF from the Panel.
3) Tear off the acetate tapes and pull out the Lamp wire from the Panel as the picture 2.
4) Unlock 6 screws and disassemble Bottom SHD from the Panel as the picture 3.
5) Tear off the long acetate tape and pull out the LVDS from the Panel as the picture 4.
PICTURE 2 PICTURE 3 PICTURE 4
