Power board
The power board part number is 1
st
Source ADPCM1910AA2, 2
nd
Source LNPCMH411KQA3 and 3
rd
Source LNPCMH411KQA4.
Before removing the power board, follow these steps:
▲ Prepare the monitor for disassembly. See Preparation for disassembly on page 11.
Remove the power board:
1) The HP OMEN 27s power board connector position is as follows:
2) Locate the part number location on the board.
Warning: After unplugging the
power supply, the capacitance
is still charged, do not touch
and discharge the capacitor.
