Installing a power supply
The computer supports power supplies that follow the ATX standard with a maximum of 1450 W.
CAUTION: To prevent damage, the overall power consumption of the computer must not exceed the
maximum rating of the computer power supply.
1. Prepare the computer for disassembly (Preparing for disassembly on page 8).
2. Remove the access panel (Removing and replacing the access panel on page 18).
3. Remove the system board tray (Installing a system board on page 25).
4. Use the security tool from the tool kit (Accessing the tool kit on page 9) to remove the power supply
cover, located on the rear of the case.
CAUTION: To avoid damaging the cover, pry only on the side of the cover as shown in the following
image.
5. Install the power supply bracket onto the power supply.
6. Route the power cables into the case, and then insert the power supply (1).
28 Chapter 2 Hardware upgrades
