HP P1100 Monitor User’s Guide
Technical Specifications
Technical Specifications
1. Use the standard image sizes to avoid distortion of the displayed image.
PICTURE TUBE
Size 21-inch Trinitron® / 19.8-inch viewable image
Phosphorous Red, Green, Blue short persistence
Dot pitch 0.25-0.27 mm stripe pitch
Face Plate Anti-glare, anti-static coating
INPUT SIGNAL
Video 0.7 Vp p analog RGB
Synchronization Separated H/V (TTL level), H/V mixed (TTL level),
Sync-on-green
INTERFACE
Input Connector 15-pin mini D-SUB; EVC
SCANNING FREQUENCY
Horizontal 30 to 107 kHz
Vertical 50 to 160 Hz
MAX. RESOLUTION (H
×
V)
1600
×
1200 (85 Hz)
WARM-UP TIME
30 minutes to reach optimum performance level
PIXEL CLOCK
230 MHz
IMAGE SIZE
At 1280
×
1024
Standard size
1
: 364(H) x 291(V) mm
Maximum size: 403(H) x 302(V) mm
At other resolutions
Standard size
1
: 388(H) x 291(V) mm
Maximum size: 403(H) x 302(V) mm
POWER SOURCE
AC 90 to 264 V, 47 to 63 Hz, 160 W (max), less than 15 W in Standby mode, less than 5 W in Sleep mode,
less than 1 W when switched off.
OPERATING ENVIRONMENT
Temperature 5
°
C to 40
°
C (operating)
- 40
°
C to +60
°
C (storage)
Operating Humidity 10% RH through 80% RH (without condensation)
CABINET DIMENSIONS
504(H)
×
498(W)
×
474(D) mm (with stand)
WEIGHT
31 kg
TILT/SWIVEL STAND
Tilt Angle - 5
°
to +15
°
Swivel Angle
±
90
°
