HP P1100 Monitor User’s Guide
Setting Up Your Display
4 English
Setting Up Your Display
Where to Place the Display
Place your display on a flat sturdy surface.
Ensure the operating site is free from excessive heat, moisture, and
sources of electromagnetic fields. Sources of electromagnetic fields
include transformers, motors, and other displays.
Connecting the Cables
NOTE Your display has two video inputs, one with a standard 15-pin VGA
connector, and one with a connector of the VESA EVC
1
standard. An
EVC cable is not provided with the display: if you wish to use this
connector — to connect more than one computer to your display, for
example — you must purchase a suitable cable from your supplier.
Before you connect any cables, refer to the safety instructions at the
beginning of this manual and make sure your PC and display are
switched off.
1. Extended Video Connector
Video cable
Power cords
1
2
3
4
lifou.bk : lif-us.fb4 Page 4 Thursday, August 28, 1997 6:47 PM
