User’s Guide B–1
B
Specifications
CRT Monitor p1230
Display
Type
22 inches
Aperture Grille CRT
55 cm
Viewable Image Size 20-inch diagonal 51 cm
Maximum Weight
(Unpacked)
66.1 lbs. 30 kg
Dimensions
(includes pedestal)
Height
Depth
Width
19.1 inches
18.8 inches
19.5 inches
48.6 mm
47.7 mm
49.5 mm
Maximum Graphics
Resolution
2048 x 1536 (85 Hz)
Recommended Text Modes 1600 x 1200 or
1280 x 1024 at 85 Hz
Stripe Pitch 0.24 mm
Horizontal Frequency 30 to 140 kHz
Vertical Refresh Rate 50 to 160 Hz
Environmental Requirements
Temperature
Operating Temperature
Non-operating Temperature
41 to 90
o
F
-4 to +140
o
F
5 to 35
o
C
-20 to +60
o
C
