HP Pavilion 14 Series User Manual

a. The panel is secured to the display enclosure with long strips of tape. Use a tweezer to grasp the tape
just above each hinge (1).
b. Pull the tape out from behind the panel (2).
NOTE: You have to pull on the tape multiple times before it is completely removed.
Display adhesive is available using spare part number L28524-001.
c. Swing the top edge of the display panel (1) forward until the panel rests upside down on the
keyboard.
d. Release the adhesive support strip (2) that secures the display panel cable connector to the display
panel.
e. Press the release lever on the side of the connector (3).
f. Disconnect the display panel cable (4) from the display panel.
58 Chapter 5 Removal and replacement procedures for Authorized Service Provider parts

HP Pavilion 14 Series Specifications

General

Display Size	14 inches
Display Resolution	1920 x 1080 (Full HD)
Processor	Intel Core i5 or AMD Ryzen 5
RAM	8GB or 16GB
Storage	256 GB / 512 GB / 1 TB SSD (varies by model)
Operating System	Windows 10 / Windows 11
Graphics	AMD Radeon Graphics
Battery Life	Up to 8 hours
Battery	3-cell Li-ion
Ports	USB Type-C, USB Type-A, HDMI, headphone/microphone combo jack
Wireless	Wi-Fi 6
