Item Component Spare part
number
(9d) For use in models with discrete graphics memory and Intel Pentium or Celeron processors 816603-001
For use in models with UMA graphics and an Intel Pentium N3540 processor (not illustrated) 833733-001
(10) Power connector cable 813945-001
(11) Hard drive (SATA; does not include bracket):
NOTE: The hard drive brackets and connector are available using spare part number 813949-001 or 829319-001 for 1
TB drives.
The hard drive cable is available using spare part number 830311-001.
For use only in HP Notebook models:
●
2-TB, 5400-rpm, hybrid 8 GB SSD, 9.5 mm 801808-005
●
1-TB, 5400-rpm, hybrid 8 GB SSD 731999-005
For use in all models:
●
1-TB, 5400-rpm, 2.5-inch 778192-005
●
750 GB, 5400 rpm hard drive, 2.5 inch 778190-005
●
500-GB, 5400-rpm, 7-mm 778186-005
For use only in HP 250/256 G4 Notebook models:
●
500-GB, 7200-rpm, 7-mm 764211-005
(12) Optical drive board 813956-001
(13) Speakers (includes left and right speakers and cable) 813965-001
(14) Optical drive (DVD+/-RW Double-Layer SuperMulti; includes bracket and bezel)
For use only in HP Notebook models 813952-001
For use only in HP 250/256 G4 Notebook models 814617-001
(15) Power button board (includes cable) 813955-001
(16) Touchpad button board (includes bracket and cables) 813954-001
(17) Battery:
4-cell, 41-Whr, 2.8-Ah Li-ion battery 807957-001
3-cell, 31-Whr, 2.8-Ah Li-ion battery 807956-001
(18) Bottom cover
For use in HP Notebook models:
●
With an optical drive 813937-001
●
Without an optical drive 813939-001
For use in HP 250/256 G4 Notebook models:
●
With an optical drive 814614-001
●
Without an optical drive 816606-001
(19) Rubber Kit (includes rear left and right feet) 813963-001
Computer major components 21
