Display assembly
This section describes removing the display assembly and disassembling display subcomponents.
If you only need to remove the display bezel, webcam/microphone module, or display panel, you do not need
to remove the entire display assembly from the computer. See Display subcomponents (bezel, webcam,
panel) on page 35 for more information about removing the display subcomponents that do not require that
you remove the entire display assembly from the computer.
Description Spare part number
Raw display panel (39.6-cm [15.6-in], HD, WLED, BrightView)
For use in models without a touch screen 813959-001
For use in models with a touch screen 813961-001
Antenna (includes wireless antenna cable and transceiver) 813923-001
Display bezel (includes Mylar screw covers)
For use in HP Notebook models 813941-001
For use in HP 250/256 G4 Notebook models 816605-001
Display cable
For use in non-touch screen models (includes display panel cable and webcam/microphone cable) 813943-001
For use in touch screen models (includes display panel cable and webcam/microphone cable) 813944-001
Display enclosure for use in HP Notebook models without a touch screen
Black models 813925-001
Red models 813929-001
White silver models 813926-001
Turbo silver models 813930-001
Blue models 813927-001
Purple models 813928-001
Rose models 831917-001
Display enclosure for use in HP Notebook models with a touch screen
Black models 813936-001
Red models 813934-001
White silver models 813931-001
Turbo silver models 813935-001
Blue models 813932-001
Purple models 813933-001
Rose models 831918-001
Display enclosure for use in HP 250/256 G4 Notebook models 814616-001
Hinges (left and right) 813950-001
Webcam/microphone module
62 Chapter 6 Removal and replacement procedures for Authorized Service Provider parts
