Page #50 background imageLoading...
Page #50 background image
Hard drive
NOTE: The hard drive spare part kit does not include the hard drive bracket.
Description Spare part number
For use only in HP Notebook models:
2-TB, 5400-rpm, hybrid 8 GB SSD, 9.5 mm 801808-005
1-TB, 5400-rpm, hybrid 8 GB SSD 731999-005
For use in all models:
1-TB, 5400-rpm, 2.5-in 778192-005
750 GB, 5400 rpm, 2.5 in 778190-005
500-GB, 5400-rpm, 7-mm 778186-005
For use only in HP 250/256 G4 Notebook models:
500-GB, 7200-rpm, 7-mm 703267-005
Hard Drive Hardware Kit (includes brackets and connector)
For use with all drives except 1 TB drives 813949-001
For use with 1 TB drives 829319-001
Hard drive cable 830311-001
Before removing the hard drive, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is o or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by rst unplugging the power cord from the AC outlet and then
unplugging the AC adapter from the computer.
4. Remove the battery (see Battery on page 32).
5. Remove the optical drive (see Optical drive on page 33), if installed.
6. Remove the bottom cover (see Bottom cover on page 39).
To remove the hard drive:
1. Disconnect the hard drive cable from the system board (1).
2. Remove the three Phillips PM2.0×2.4 screws (2) that secure the hard drive assembly to the computer.
42 Chapter 6 Removal and replacement procedures for Authorized Service Provider parts
