Display assembly subcomponents
Item Component Spare part number
(1) Display bezel (includes Mylar screw covers)
For use in HP Notebook models 813941-001
For use in HP 250/256 G4 Notebook models 816605-001
(2) Raw display panel (39.6-cm [15.6-in], HD, WLED)
For use in all models without a touch screen (BrightView) 813959-001
For use in all models with a touch screen (BrightView) 813961-001
For use in HP 250/256 G4 models (AntiGlare) 826812-001
(3) Hinges (left and right) 813950-001
(4) Webcam/microphone module
For use in HP Notebook models 813972-001
For use in HP 250/256 G4 Notebook models 814613-001
(5) Antenna (includes wireless antenna cable and transceiver) 813923-001
24 Chapter 3 Illustrated parts catalog
