c. Remove the webcam/microphone module (2). (The module is attached to the display enclosure
with double-sided tape.)
3. To remove the display panel:
a. Remove the four Phillips PM2.0×2.4 screws (1) that secure the display panel to the enclosure.
b. Rotate the display panel out of the enclosure (2) to gain access to the display cable connection on
the back of the panel.
NOTE: In this procedure, the display will NOT be connected to the computer, as shown in the
following image.
66 Chapter 6 Removal and replacement procedures for Authorized Service Provider parts
