HP Pavilion 16 User Manual

To reassemble and replace the display assembly, reverse the removal procedures.
Touchpad cable
To remove the touchpad cable, use this procedure and illustration.
Table 5-9 Touchpad description and part number
Description Spare part number
Touchpad cable (includes double-sided adhesive) N94794-001
Before removing the touchpad cable, follow these steps:
1. Prepare the computer for disassembly (see Preparation for disassembly on page 33).
2. Remove the bottom cover (see Bottom cover on page 33).
3. Disconnect the battery cable from the computer (see Battery on page 35).
Remove the touchpad cable:
1. Release the ZIF connector (1) the touchpad cable is connected to, and then disconnect the
touchpad cable from the system board.
2. Release the ZIF connector (2) the touchpad cable is connected to, and then disconnect the
touchpad cable from the touchpad.
3. Detach the touchpad cable (3) from the computer. The touchpad cable is attached to the computer
with double-sided adhesive.
4. Remove the touchpad cable.
To replace the touchpad cable, reverse the removal procedures.
52
Chapter 5 Removal and replacement procedures for authorized service provider parts

HP Pavilion 16 Specifications

General

Series	Pavilion
RAM	16 GB DDR4
Storage	1TB SSD
Operating System	Windows 11
Ports	1 x HDMI, 1 x headphone/microphone combo, 1 x SD card reader
Wireless	Wi-Fi 6 and Bluetooth 5
Battery	Up to 8 hours (depending on configuration and usage)
