HP Pavilion 17-AR050WM User Manual

83 pages

To Next Page

To Previous Page

Component Description

(7) AC adapter and battery light (continued)

●

O: The battery is not charging.

(8) Power connector Connects an AC adapter.

Right side 5

Table of Contents5
Product Description9
Getting to Know Your Computer11
Locating Hardware11
Locating Software11
Right Side12
Left Side14
Display15
Keyboard Area16
Touchpad16
Lights17
Button and Speakers18
Special Keys19
Bottom20
Illustrated Parts Catalog21
Locating the Model Number, Serial Number, Product Number, and Warranty Information21
Computer Components22
Display Assembly Components25
Miscellaneous Parts26
Removal and Replacement Preliminary Requirements27
Tools Required27
Service Considerations27
Plastic Parts27
Cables and Connectors28
Drive Handling28
Grounding Guidelines29
Electrostatic Discharge Damage29
Packaging and Transporting Guidelines30
Workstation Guidelines30
Removal and Replacement Procedures32
Component Replacement Procedures32
Optical Drive32
Bottom Cover33
Battery35
Hard Drive36
WLAN Module37
Memory Module38
Connector Board40
Touchpad Cable41
Touchpad42
Fan44
System Board45
Heat Sink48
Connector Board Cable50
Optical Drive Cable51
Speakers52
Display Assembly54
Power Connector Cable62
Computer Setup (BIOS), TPM, and HP Sure Start64
Using Computer Setup64
Starting Computer Setup64
Navigating and Selecting in Computer Setup64
Restoring Factory Settings in Computer Setup65
Updating the BIOS66
Determining the BIOS Version66
Downloading a BIOS Update66
Changing the Boot Order Using the F9 Prompt67
TPM BIOS Settings (Select Products Only)68
Using HP Sure Start (Select Products Only)68
HP PC Hardware Diagnostics (UEFI)69
Downloading HP PC Hardware Diagnostics (UEFI) to a USB Device70
Specifications71
Backing up and Recovering72
Creating Recovery Media and Backups72
Creating HP Recovery Media (Select Products Only)73
Using Windows Tools74
Restore and Recovery74
Recovering Using HP Recovery Manager75
What You Need to Know before You Get Started75
Using the HP Recovery Partition (Select Products Only)76
Using HP Recovery Media to Recover76
Changing the Computer Boot Order77
Removing the HP Recovery Partition (Select Products Only)77
10 Power Cord Set Requirements78
Requirements for All Countries78
Requirements for Specific Countries and Regions78
11 Recycling80
Index81
