Item Description Spare part number
(15) Memory modules (PC3-10600, 1333-MHz)
4096-MB 599092-001
2048-MB 598856-001
(16) Battery
9-cell, 100-WH (3.0-Ah) Li-ion 636631-001
6-cell, 62-WH (2.80-Ah) Li-ion 593562-001
6-cell, 55-WH (2.55-Ah) Li-ion 593554-001
(17) Base enclosure (includes modem cable and optical drive cable) 608223-001
(18) Hard drive (includes hard drive bracket)
NOTE: The hard drive cable is included in the Misc Cable Kit, spare part number 608227-001.
750-GB, 7200 RPM 678103-001
640-GB, 7200 RPM 678102-001
500-GB, 7200 RPM 678101-001
320-GB, 7200 RPM 678100-001
160-GB solid-state drive 608215-001
(19) DVD±RW SuperMulti DL Drive (12.7 mm optical drive, fixed) 608221-001
24 Chapter 3 Illustrated parts catalog
