Removal and replacement procedures
Maintenance and Service Guide 4–37
✎
Steps 22 through 38 provide display assembly internal component removal information for computer models
equipped with BrightView display assemblies.
22. If it is necessary to replace the display bezel or any of the display assembly internal components, remove the
Mylar screw covers 1 and the two Phillips PM2.5×6.0 screws 2 on the display bezel lower edge.
23. Flex the inside edges of the top edge 1, the left and right sides 2, and the bottom edge of the display bezel
3 until the bezel disengages from the display enclosure.
24. Remove the display bezel 4. The display bezel is available using the following spare part numbers:
❏ 531794-001—for use only with dv3-2000 computer models equipped with a 13.4-inch display assembly
❏ 531788-001—for use only with computer models equipped with a 13.3-inch display assembly.
