HP Pavilion DV5000 - Modem, LAN, and Security; Modem Connection and Troubleshooting

Removal and Replacement Procedures
Maintenance and Service Guide 5–49
2. Remove the Phillips PM2.0×4.0 screw 1 that secures the
Bluetooth module to the base enclosure.
3. Remove the Bluetooth module from the base enclosure 2.
4. Remove the Bluetooth module cable 3 from the routing
channel in the base enclosure.
5. Disconnect the Bluetooth module cable 4 from the Bluetooth
module.
✎
The Bluetooth module cable is included with the Bluetooth
module and is also available in the Cable Kit, spare part
number 407774-001.
Removing the Bluetooth module
Reverse the above procedure to install the Bluetooth board.
