Removal and Replacement Procedures
Maintenance and Service Guide 5–71
5.23 PC Card Assembly
1. Prepare the computer for disassembly (Section 5.3),
and then remove the following components:
a. Hard drive (Section 5.4)
b. Memory/Mini PCI module compartment cover
(Section 5.6)
c. Optical drive (Section 5.9)
d. Switch cover (Section 5.10)
e. Keyboard assembly (Section 5.11)
f. Display assembly (Section 5.14)
g. Top cover (Section 5.15)
h. System board (Section 5.17)
PC Card Assembly Spare Part Number Information
PC Card assembly 407829-001
