Removal and Replacement Procedures

Maintenance and Service Guide 5–25

5.12 LED Board

1. Prepare the computer for disassembly (Section 5.3) and then

remove the following components:

a. Memory/Mini PCI module compartment cover

(Section 5.6)

b. Switch cover (Section 5.10)

c. Keyboard frame (Section 5.11)

2. Turn the keyboard frame upside down with the LED board

toward you.

LED Board Spare Part Number Information

✎

LED board spare part kits include the LED board cable.

For use with full-featured models

For use with defeatured models

407787-001

407788-001
